Integrating your Reolink Lumus camera with Home Assistant opens up a world of possibilities for home automation and security. This guide will walk you through the process step-by-step, ensuring a smooth and successful integration. Guys, get ready to level up your smart home game!

Prerequisites

Before we dive in, make sure you have the following:

• A Reolink Lumus camera. Obviously, right?
• A working Home Assistant installation. If you don't have one yet, set it up first!
• Your Reolink Lumus camera's IP address. You'll need this to connect it to Home Assistant.
• The username and password for your Reolink Lumus camera. Keep these handy!
• Basic familiarity with Home Assistant configuration files. Don't worry, we'll guide you through it.

Step 1: Enable RTSP and HTTP on your Reolink Lumus

First things first, you need to enable RTSP (Real Time Streaming Protocol) and HTTP on your Reolink Lumus camera. This allows Home Assistant to communicate with the camera and receive video feeds. Here's how:

1. Open the Reolink app on your smartphone or access the Reolink client on your computer.
2. Navigate to the camera's settings. Look for something like "Network Settings" or "Advanced Settings."
3. Find the RTSP and HTTP settings. They might be under "Streaming" or "Port Settings."
4. Enable both RTSP and HTTP. Make sure to note the RTSP port (usually 554) and the HTTP port (usually 80 or 443). These are important, so write them down!
5. Save the changes. Your camera might restart to apply the new settings. Give it a minute to come back online.

Why is this step important? Without enabling RTSP, Home Assistant can't directly access the video stream from your camera. HTTP access is also crucial for certain functionalities and integrations. So, make sure you don't skip this step!

Troubleshooting Tip: If you're having trouble finding these settings, consult your Reolink Lumus camera's manual or search for specific instructions online. Reolink's website and community forums are great resources.

Step 2: Add the Reolink Camera to Home Assistant

Now that your Reolink Lumus is ready, let's add it to Home Assistant. There are a couple of ways to do this, but we'll focus on the most common and reliable method: using the configuration.yaml file.

1. Access your Home Assistant configuration directory. This is usually located in /config on your Home Assistant server.

2. Open the configuration.yaml file using a text editor. Be careful when editing this file, as incorrect syntax can cause Home Assistant to fail to start.

3. Add the following lines to your configuration.yaml file:

   camera:
     - platform: ffmpeg
       name: Reolink Lumus
       input: -rtsp_transport tcp -i rtsp://USERNAME:PASSWORD@CAMERA_IP:554/h264Preview_01_main


   • Replace USERNAME with your Reolink Lumus camera's username.
   • Replace PASSWORD with your Reolink Lumus camera's password.
   • Replace CAMERA_IP with your Reolink Lumus camera's IP address.
   • Ensure the port number (:554) matches the RTSP port you noted earlier.

4. Save the configuration.yaml file.

5. Restart Home Assistant. This is crucial for the changes to take effect. You can usually restart Home Assistant from the web interface under "Configuration" -> "Server Controls."

Understanding the Configuration:

• platform: ffmpeg: This tells Home Assistant to use the FFmpeg integration to handle the video stream.
• name: Reolink Lumus: This sets the name of the camera in Home Assistant. You can choose any name you like.
• input: This specifies the RTSP URL of your camera. The -rtsp_transport tcp option forces the use of TCP for the RTSP connection, which can improve stability in some cases.

Alternative Configuration (using the Reolink Integration):

Home Assistant also has a dedicated Reolink integration. To use this, you'll need to install it via HACS (Home Assistant Community Store). Once installed, you can configure it through the Home Assistant UI. This integration offers more features, such as motion detection and PTZ control (if your camera supports it).

Step 3: Verify the Integration

After restarting Home Assistant, it's time to verify that the Reolink Lumus camera is successfully integrated.

1. Open the Home Assistant web interface.
2. Navigate to the Lovelace UI (your dashboard).
3. Add a new card (or edit an existing one) to display the camera feed.
4. Choose the "Picture Entity" or "Picture Glance Card."
5. Select your Reolink Lumus camera from the list of available entities.
6. Save the card.

If everything is working correctly, you should now see the live video feed from your Reolink Lumus camera in your Home Assistant dashboard. Awesome!

Troubleshooting:

• If you don't see the camera feed, double-check your configuration.yaml file for errors. Make sure the IP address, username, and password are correct.
• Check the Home Assistant logs for any error messages related to the camera. This can provide valuable clues about what's going wrong.
• Ensure that your Reolink Lumus camera is connected to the same network as your Home Assistant server.
• Try restarting your Reolink Lumus camera and your Home Assistant server.

Step 4: Advanced Configuration (Optional)

Once you have the basic integration working, you can explore some advanced configuration options to further enhance your setup. Here are a few ideas:

• Motion Detection: Configure motion detection using the Reolink Lumus camera's built-in motion sensor. This allows you to trigger automations in Home Assistant when motion is detected (e.g., turn on lights, send notifications).
• PTZ Control: If your Reolink Lumus camera supports pan, tilt, and zoom (PTZ) functionality, you can add controls to your Home Assistant dashboard to remotely control the camera's position.
• Recording: Set up recording of the video feed to a local storage device or a network drive. This can be useful for security purposes or for reviewing past events.
• Automations: Create automations that use the camera's state (e.g., motion detected, online/offline) to trigger other actions in your smart home. For example, you could create an automation that sends you a notification when motion is detected at night.

Example Automation:

Here's an example of an automation that sends a notification when motion is detected by the Reolink Lumus camera:

automation:
  - alias: Reolink Lumus Motion Detected
    trigger:
      - platform: state
        entity_id: binary_sensor.reolink_lumus_motion
        to: "on"
    action:
      - service: notify.mobile_app_YOUR_PHONE
        data:
          title: Motion Detected!
          message: Motion detected by the Reolink Lumus camera.

Replace binary_sensor.reolink_lumus_motion with the actual entity ID of your camera's motion sensor and notify.mobile_app_YOUR_PHONE with the service name of your notification platform.

Conclusion

Integrating your Reolink Lumus camera with Home Assistant is a fantastic way to enhance your home security and automation capabilities. By following the steps outlined in this guide, you can seamlessly integrate your camera and unlock a world of possibilities. So, go ahead and give it a try! And if you have any questions, don't hesitate to ask in the comments below.

Final Thoughts:

Remember to always keep your camera's firmware up to date and use strong passwords to protect your privacy. With a little bit of effort, you can create a powerful and secure smart home system with your Reolink Lumus and Home Assistant. Happy automating!
